High Density Ceramic Fiber Board, Ceramic fiber Furnace Chamber
Brother ceramic fiberboard is made of high purity alumina fibrous and alumina powder, to be formed and fired in special equipment with the advanced patent process, can withstand temperature up to 1800 Celsius.
Features:
Max.temperature: 1800℃
Density: 320-600kg/m3
Color: white
Low thermal conductivity and less shrinkage
Excellent mechanism and structure strength
- Smooth surface.
- Average thickness and density.
- Excellent mechanism and structural strength.
- Low thermal conductivity and less shrinkage Super light weight.
Ceramic Fiber Board Types:
| Type | BR-1000 | BR-1260 | BR-1400 | BR-1600 | BR-1700 | BR-1800 |
| Classification temperature | 1000 | 1260 | 1400 | 1600 | 1700 | 1800 |
| density (Kg/m3) | 200-600 | 200-600 | 200-600 | 200-600 | 350-600 | 350-600 |
| Line change(.CX24hS) | 1.3 (900.C) |
1.1 (1100.C) |
1.6 (1200.C) |
<2.0 (1400.C) |
<2.0 (1500.C) |
<2.0 (1600.C) |
| compressive strength | 0.5 | 0.5 | 0.5 | 0.3 | 0.3 | 0.3 |
Ceramic Fiber Board Physical Character:
| Density (Kg/m3) | 400 | |
| Strength to resist bending (MPa,25.C) | 0.72 | |
| Linear shrinkage rate % (1600 .Cx8hrs) | 0.13(1.7)* | |
| Expansion rate at % (600℃) | 0.28 | |
| Average modulus of linear expansion (x10-6/K) | 1.77 | |
| Thermal conductivity rate GHP[W/(mK)] | 400.C | 0.147 |
| 600.C | 0.186 | |
| 800.C | 0.236 | |
| 1000.C | 0.296 | |
| Chemical composition | AL2O3:87% SiO2:13% | |
Application
| Character | Product applying |
| High-temperature steady | Verity high-temperature industrial furnace backing heat insulation |
| low heat conductivity | Ceramics kiln, mechanic and metallurgy heating furnace, thermal treatment furnace and other industrial furnace and hot face internal lining Low heating quantity High-temperature block-fire and flame-insulated |
| easy-mechanic processing | Kiln door, kiln car, and dilatation joint, insulation material, etc. |
| Tidy surface | Glass kiln insulation |
Ceramic Fiber Board Standard Size
- 25x600x900mm
- 40x600x900mm
- 30x600x900mm
- 50x600x900mm
- 100x600x900mm
* Other size can be customizable.
